• Няма наличност
Дънна платка MSI PRO B760-P WIFI DDR4, LGA1700 - 911-7D98-001
Дънна платка MSI PRO B760-P WIFI DDR4, LGA1700 - 911-7D98-001
Дънна платка MSI PRO B760-P WIFI DDR4, LGA1700 - 911-7D98-001
Дънна платка MSI PRO B760-P WIFI DDR4, LGA1700 - 911-7D98-001
Дънна платка MSI PRO B760-P WIFI DDR4, LGA1700 - 911-7D98-001

Дънна платка MSI PRO B760-P WIFI DDR4, LGA1700 - 911-7D98-001

MSI
145,00 €
Цената е с включен ДДС.
Няма наличност

Изпрати ми известие, когато има наличност

Interested in this product? Drop us an email and we will let you know when it's available for order.

Видео карта 1x HDMI™; 1x DisplayPort; Support HDMI™ 2.1, maximum resolution of 4K 60Hz*; Support DP 1.4, maximum resolution of 4K 60Hz*
CPU's supported Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors LGA 1700
Чипсет INTEL B760
Expansion Slots 5x PCI-E x16 slot; PCI_E1 PCIe 4.0 supports up to x16 (From CPU); PCI_E2 PCIe 3.0 supports up to x1 (From Chipset); PCI_E3 PCIe 4.0 supports up to x16 (From Chipset); PCI_E4 PCIe 3.0 supports up to x1 (From Chipset); PCI_E5 PCIe 3.0 supports up to x1 (From Chipset)
Storage 2x M.2 slot; M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices; M.2_2 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices; 4x SATA 6G port
Тип памет 4x DDR4, Maximum Memory Capacity 128GB; Memory Support 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC); Max. overclocking frequency: • 1DPC 1R Max speed up to 5333+ MHz; • 1DPC 2R Max speed up to 4800+ MHz; • 2DPC 1R Max speed up to 4400+ MHz; • 2DPC 2R Max speed up to 4000+ MHz; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Intel® Extreme Memory Profile (XMP)
Вх/Изх Keyboard / Mouse; DisplayPort; 2.5G LAN; USB 2.0; Wi-Fi / Bluetooth; Audio Connectors; USB 2.0; HDMI™; USB 3.2 Gen 2 10Gbps (Type-A); USB 3.2 Gen 2 10Gbps (Type-C); S/PDIF-OUT
Конектори 1x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x CPU Fan; 1x Pump Fan; 5x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Printer Port (JLPT); 1x Com Port (JCOM); 1x TBT connector (JTBT, supports RTD3); 2x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 1x TPM pin header(Support TPM 2.0); 4x USB 2.0; 2x USB 3.2 Gen1 Type A; 1x USB 3.2 Gen1 Type C
Audio Realtek® ALC897 Codec; 7.1-Channel High Definition Audio
LAN Realtek® RTL8125BG 2.5G LAN
Форм фактор ATX,243.84mmx304.8mm
OS Support for Windows® 11 64-bit, Windows® 10 64-bit
Друго Intel® Wi-Fi 6E; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax; Supports Bluetooth® 5.3, FIPS, FISMA
Гаранция 36 Months

  • Марка
  • Референция
    911-7D98-001
  • EAN13
    4711377028363

  • Производител
    MSI
  • Сокет
    LGA1700
  • Чипсет
    Intel B760
  • Поддържани процесори
    Intel
  • Поддържана памет на дънна платка
    DDR4
  • Форм фактор
    ATX
  • RAM слотове
    4
  • Гаранция
    36 месеца
  • Портове на лаптоп
    Display Port
    HDMI
    M.2 PCI-E за SSD
    RJ-45 LAN
    SPDIF
    USB 2
    USB 3
    USB Type C
