1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz; 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz; 1 x HDMI™ port, supports a maximum resolution of 4096x2160@30H
CPU's supported
Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
Chipset
Intel® H310 Chipset; This chipset is ME11 firmware based and doesn’t feature SDA3.0.
Expansion Slots
1 x PCIe 3.0 x16 slot; 2 x PCIe 2.0 x1 slots
Storage
Intel® H310 Chipset; 4 x SATA 6Gb/s ports; Supports Intel® Rapid Storage Technology
Memory type
2 x DDR4 memory slots, support up to 32GB; Supports DDR4 2666/ 2400/ 2133 MHz (by JEDEC)1; Supports DDR4 2666/ 2400/ 2133 MHz (by XMP OC)1; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Intel® Extreme Memory Profile (XMP)
I/O
PS/2 Combo Port; VGA Port; HDMI Port; USB 3.1 Gen1; LAN Port; HD Audio Connectors; USB 2.0 Port; DVI-D Port; USB 2.0 Port
Connectors
1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 4 x SATA 6Gb/s connectors; 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports); 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports); 1 x Clear CMOS jumper; 2 x Front panel connectors; 1 x Serial port connector; 1 x TPM module connector; 1 x Chassis Intrusion connector; 1 x Front panel audio connector; 1 x 4-pin CPU fan connector; 1 x 4-pin system fan connector
Audio
Realtek® ALC887 Codec; 7.1-Channel High Definition Audio
LAN
1 x RTL8111H Gigabit LAN controller
Form Factor
8.9 in. x 7.3 in. (22.6 cm x 18.5 cm); m-ATX Form Factor
